Kaiser Copylizer "eVision ini.tial" HF

SKU: 205206 | FREE U.S. shipping on all orders over $100!

$2,999.99
Students and Educators: Enroll or Log in for exclusive EDU savings!
Notify me Find a dealer

Out of stock

  • Height-adjustable feet
  • RA 101 camera arm with camera body positioning device and interchangeable 1/4” and 3/8” threads
  • Illumina base with high-frequency operation system (approx. 40 kHz) for flicker-free operation, especially important for use with digital scanning cameras

Overview

Illumina base with high-frequency operation system (approx. 40 kHz) for flicker-free operation, especially important for use with digital scanning cameras.

Specifications

Base Board Dimensions (in):
12.6x17.7
Base Board Dimensions (mm):
320x450
Base Board Type:
Illuminated
Bushing Thread Mount (in):
1/4"-20, 3/8"-16
Camera Arm Type:
RA-101 Camera Arm
Color Temperature (Kelvin):
5000
Column Cross Section (in):
2.8
Column Cross Section (mm):
70
Column Height (in):
26.4
Column Height (cm):
67
Distance from Column/Vertical Arm to Edge of Light (cm):
11.7
Distance from Column/Vertical Arm to Edge of Light (in):
4.6
High Frequency Operation:
~ 40 kHz
Illuminated Area Dimensions (in):
7.9x7.1
Illuminated Area Dimensions (cm):
20x18
Are Lamp Bulbs Replaceable:
yes
Luminance (cd/m2):
4600
Maximum Payload Capacity (lb):
8.8
Maximum Payload Capacity (kg):
4
Physical:

Original Width for focal length (in/cm) 100 mm:
6.7/18
Original Width for focal length (in/cm) 50 mm:
13.8/36
Power Cord:
1
Power Cord Length (cm):
250
Power Cord Length (in):
78
Power Supply Voltage:
110
Power/Wattage (watts):
4 x 8
Product Weight (kg):
12.9kg
Product Weight (lb):
28.44lb
Replacement Lamp Part Number:
202146, 202475
Vertical Arm Height (cm):
73
Vertical Arm Height (in):
28.7
Warranty:
2 Year
