Nanlite | SKU: FL-20G
- ULTRA BRIGHT OUTPUT - Equipped with the included reflector, the Forza 300B emits an impressive 37440 Lux at 1 meter with a color temperature of 5600K. Plus, with dimming from 100% down to 1%, you can quickly adapt the Forza 300B to any scene without adding ND filters or diffusion.
- VARIABLE BICOLOR: The Forza 300B employs a COB LED module with a variable color temperature range from 2700K to 6500K, enabling you to quickly match natural ambient or artificial lighting situations at the twist of a dial eliminating the need for gels.
- BOWENS STYLE LIGHT MODIFIER MOUNT: By utilizing the near-universal Bowens style light modifier mount and incorporating an umbrella holder into the yolk, the Forza 300B is compatible with a massive selection of light modifiers. Including, but not limited to, Nanlite's line of fresnels, softboxes, and umbrellas.
- LIGHTWEIGHT COMPACT DESIGN - Created to eliminate the difficulties of traveling with large light fixtures, the Forza 300B weighs only 11.11 lbs (5.07 lbs of the head, 6.04 lbs of the controller and power supply) and is compact enough to be easily packed into most gear cases.
- POWER ANYWHERE - Optimized for use in the studio or on location, the Forza 300B can run off either the included AC adapter or 2x 14.8V V-Mount batteries (Not Included), so you can operate in any location regardless of power availability.
Overview
The Forza 300B from Nanlite is a bi-color LED spotlight engineered to provide maximum output from a fixture with a minimal footprint. The Forza 300B employs a COB LED module in a head that weighs only 5.07 lbs, and a precision-engineered reflector emits 39180 Lux at 1 meter with the color temperature set to 5600K. All while maintaining a high average CRI and TLCI of 96/98, ensuring accurate color rendition.
Ultra Bright Output
Equipped with the included reflector, the Forza 300B emits an impressive 39180 Lux at 1 meter with a color temperature of 5600K. When equipped with the optional FL-20G fresnel, the light output climbs to a staggering 170760 Lux at 1 meter. Plus, with dimming from 100% down to 1%, you can quickly adapt the Forza 300B to any scene without adding ND filters or diffusion.
Variable Bi-Color
The Forza 300B employs a COB LED module with a variable color temperature range from 2700K to 6500K, enabling you to quickly match natural ambient or artificial lighting situations at the twist of a dial eliminating the need for gels.
Lightweight Compact Design
Created to eliminate the difficulties of traveling with large light fixtures, the Forza 300B weighs only 11.11 lbs (5.07 lbs of the head, 6.04 lbs of the controller and power supply) and is compact enough to be easily packed into most gear cases.
Color Perfection
The brightness of a light is important, but without color accuracy, you will end up spending a ton of time and money in post-production. The Forza 300B features an average CRI of 96 and an average TLCI of 98, meaning you can shoot confidently knowing the color reproduction will be precise.
Endless Light-Shaping Possibilities
By utilizing the near-universal Bowens style light modifier mount and incorporating an umbrella holder into the yolk, the Forza 300B is compatible with a massive selection of light modifiers. Including, but not limited to, Nanlite's line of fresnels, softboxes, and umbrellas.
Practical Effects
With 12 pre-programmed special effects in a simple-to-master menu system, the Forza 300B makes it easy to imitate lighting scenarios that can otherwise be tricky to recreate. Effects include CCT Loop, INT Loop, Flash, Pulse, Storm, TV, Paparazzi, Candle/Fire, Bad Bulb, Firework, Explosion, and Welding.
Satellite Control and Power Station
To keep a low center of gravity and the controls easily accessible, the Forza 300B's control panel, AC adapter, and battery plate have been combined into one satellite unit conveniently hung from any light stand. The satellite also serves as the DMX/RDM connection point enabling the Forza 300 to be quickly adopted into any DMX controlled environment.
Power Anywhere
Optimized for use in the studio or on location, the Forza 300B can run off either the included AC adapter or 2x 14.8V V-Mount batteries (Not Included), so you can operate in any location regardless of power availability.
Studio and Location Ready
Supplied with a standard 5/8" receiver mount, the Forza 300B can be mounted directly on any standard light stand, and the 360-degree rotating yolk makes it easy to adjust any angle or even hang the light from a ceiling for studio use.
Read More
Ultra Bright Output
Equipped with the included reflector, the Forza 300B emits an impressive 39180 Lux at 1 meter with a color temperature of 5600K. When equipped with the optional FL-20G fresnel, the light output climbs to a staggering 170760 Lux at 1 meter. Plus, with dimming from 100% down to 1%, you can quickly adapt the Forza 300B to any scene without adding ND filters or diffusion.
Variable Bi-Color
The Forza 300B employs a COB LED module with a variable color temperature range from 2700K to 6500K, enabling you to quickly match natural ambient or artificial lighting situations at the twist of a dial eliminating the need for gels.
Lightweight Compact Design
Created to eliminate the difficulties of traveling with large light fixtures, the Forza 300B weighs only 11.11 lbs (5.07 lbs of the head, 6.04 lbs of the controller and power supply) and is compact enough to be easily packed into most gear cases.
Color Perfection
The brightness of a light is important, but without color accuracy, you will end up spending a ton of time and money in post-production. The Forza 300B features an average CRI of 96 and an average TLCI of 98, meaning you can shoot confidently knowing the color reproduction will be precise.
Endless Light-Shaping Possibilities
By utilizing the near-universal Bowens style light modifier mount and incorporating an umbrella holder into the yolk, the Forza 300B is compatible with a massive selection of light modifiers. Including, but not limited to, Nanlite's line of fresnels, softboxes, and umbrellas.
Practical Effects
With 12 pre-programmed special effects in a simple-to-master menu system, the Forza 300B makes it easy to imitate lighting scenarios that can otherwise be tricky to recreate. Effects include CCT Loop, INT Loop, Flash, Pulse, Storm, TV, Paparazzi, Candle/Fire, Bad Bulb, Firework, Explosion, and Welding.
Satellite Control and Power Station
To keep a low center of gravity and the controls easily accessible, the Forza 300B's control panel, AC adapter, and battery plate have been combined into one satellite unit conveniently hung from any light stand. The satellite also serves as the DMX/RDM connection point enabling the Forza 300 to be quickly adopted into any DMX controlled environment.
Power Anywhere
Optimized for use in the studio or on location, the Forza 300B can run off either the included AC adapter or 2x 14.8V V-Mount batteries (Not Included), so you can operate in any location regardless of power availability.
Studio and Location Ready
Supplied with a standard 5/8" receiver mount, the Forza 300B can be mounted directly on any standard light stand, and the 360-degree rotating yolk makes it easy to adjust any angle or even hang the light from a ceiling for studio use.
Technical Data
- Accepts Grids:
- Not Applicable
- Accessory Port(s):
- Not Applicable
- Amp-Hours:
- Not Applicable
- Battery Capacity (Wh):
- Not Applicable
- Battery Cells:
- Not Applicable
- Battery Chemistry:
- Not Applicable
- Battery Compatibility:
- Sony V-Mount 14.8V Battery(Not Included)
- Battery Included:
- No
- Battery Maximum Output Voltage:
- Not Applicable
- Battery Required:
- No
- Beam Angle Flood:
- 45 Degrees (Requires FL-20G Fresnel)
- Beam Angle Spot:
- 10 Degrees (Requires FL-20G Fresnel)
- Channels:
- Not Applicable
- Charge Time to Full (Hours):
- Battery Dependent
- Charge Time to 80% (Hours):
- Battery Dependent
- Charger:
- Not Applicable
- Closed Length (cm):
- Not Applicable
- Closed Length (in):
- Not Applicable
- Color Temperature (Kelvin):
- 2700K-6500K
- Compatible D-Tap Adapter:
- Not Applicable
- Compatible Remote:
- WS-RC-C2 Remote Control
- Compatible Wifi Adapter:
- Nanlink WS-TB-1 Transmitter Box
- Cooling System:
- Active Silent Fan
- CRI:
- Average 96
- Depth Rating:
- IP 20
- Dimming:
- 0-100%
- DMX Control:
- Yes
- Electrical Load Capacity:
- Not Applicable
- Footprint Diameter (cm):
- cm
- Footprint Diameter (in):
- in
- Frequency:
- 2.4GHz
- Groups:
- Not Applicable
- Includes Rechargeable Battery:
- No
- Interior Color:
- Not Applicable
- Light Modifier Bayonet Mount:
- Bowens Style
- Load Capacity (kg):
- Not Applicable
- Load Capacity (lb):
- Not Applicable
- Lumen Output 3200K:
- 13304
- Lumen Output 5600K:
- 18066
- Lux @ 0.5m 5600K:
- Not Applicable
- Lux @ 1m 2700K:
- 6388
- Lux @ 1m 3200K:
- 6646
- Lux @ 1m 5600K:
- 8901
- Max Power Consumption:
- 355W
- Maximum Height (in):
- Not Applicable
- Maximum Height (cm):
- Not Applicable
- Physical:
- Minimum Height (cm):
- Not Applicable
- Minimum Height (in):
- Not Applicable
- Mount:
- Standard 5/8" Receiver with Rotating Yoke
- Number of Rods:
- Not Applicable
- Operating Temperature:
- Not Applicable
- Power Source:
- DC48V/8.4A Max AC100-240V 50/60Hz
- 'Product Diameter (cm):
- Not Applicable
- 'Product Diameter (in):
- Not Applicable
- Product Inner Diameter (cm) Ring Lights Only:
- Not Applicable
- Product Inner Diameter (in) Ring Lights Only:
- Not Applicable
- Product Height (cm):
- 22.5cm
- Product Height (in):
- 8.86in
- Product Length (cm):
- 33.0cm
- Product Length (in):
- 12.99in
- Product Weight (kg):
- 2.7kg
- Product Weight (lb):
- 6.4lb
- Product Width (cm):
- 12.0cm
- Product Width (in):
- 4.72in
- Removable Front Diffusion:
- Not Applicable
- Removable Interior Baffle:
- Not Applicable
- Requires Speed Ring:
- Not Applicable
- Runtime @ 100% Brightness (Hours):
- (2x) 14.8V Sony V-Mount Style 130WH: 49 mins
- Runtime @ 50% Brightness (Hours):
- (2x) 14.8V Sony V-Mount Style 130WH: 2 hours 12 mins
- Runtime @ 10% Brightness (Hours):
- (2x) 14.8V Sony V-Mount Style 130WH: 11 hours 54 mins
- Shape:
- Not Applicable
- TLCI:
- Average 98
- Umbrella Shaft Diameter:
- Not Applicable
- Warranty:
- Limited 2-Year Warranty (Extend to 3 Years Total with Online Registration)
- Wireless Control Type:
- 2.4GHz Bluetooth
- Wireless Range:
- Not Applicable
Lux / Foot Candles
| Bare Bulb and Reflector | With Optional FL-20G | ||
|---|---|---|---|
| @ 1m 2700K | 6388 lux / 593.4 fc | @ 1m 2700K Spot | 123200 lux / 11445.6 fc |
| @ 2m 2700K | 1660 lux / 154.2 fc | @ 2m 2700K Spot | 30800 lux / 2861.4 fc |
| @ 3m 2700K | 784 lux / 72.8 fc | @ 3m 2700K Spot | 13133 lux / 1220.1 fc |
| @ 1m 2700K with Reflector | 28540 lux / 2651.4 fc | @ 1m 2700K Flood | 17650 lux / 1639.7 fc |
| @ 2m 2700K with Reflector | 6450 lux / 599.2 fc | @ 2m 2700K Flood | 4826 lux / 448.3 fc |
| @ 3m 2700K with Reflector | 2754 lux / 255.8 fc | @ 3m 2700K Flood | 2245 lux / 208.5 fc |
| @ 1m 3200K | 6646 lux / 617.4 fc | @ 1m 3200K Spot | 130470 lux / 12121 fc |
| @ 2m 3200K | 1724 lux / 160.1 fc | @ 2m 3200K Spot | 32120 lux / 2984 fc |
| @ 3m 3200K | 864 lux / 80.2 fc | @ 3m 3200K Spot | 13523 lux / 1256.3 fc |
| @ 1m 3200K with Reflector | 29520 lux / 2742.5 fc | @ 1m 3200K Flood | 18350 lux / 1704.7 fc |
| @ 2m 3200K with Reflector | 6669 lux / 619.5 fc | @ 2m 3200K Flood | 4954 lux / 460.2 fc |
| @ 3m 3200K with Reflector | 2963 lux / 275.2 fc | @ 3m 3200K Flood | 2542 lux / 236.1 fc |
| @ 1m 5600K | 8901 lux / 826.9 fc | @ 1m 5600K Spot | 24420 lux / 2268.7 fc |
| @ 2m 5600K | 2293 lux / 213 fc | @ 2m 5600K Spot | 42690 lux / 3966 fc |
| @ 3m 5600K | 1174 lux / 109 fc | @ 3m 5600K Spot | 17557 lux / 1631 fc |
| @ 1m 5600K with Reflector | 39180 lux / 3639.9 fc | @ 1m 5600K Flood | 20860 lux / 1938 fc |
| @ 2m 5600K with Reflector | 8755 lux / 813.3 fc | @ 2m 5600K Flood | 6600 lux / 613.1 fc |
| @ 3m 5600K with Reflector | 3984 lux / 370.1 fc | @ 3m 5600K Flood | 2907 lux / 270 fc |
| @ 1m 6500K | 9650 lux / 896.5 fc | @ 1m 6500K Spot | 185760 lux / 17257.6 fc |
| @ 2m 6500K | 2523 lux / 234.4 fc | @ 2m 6500K Spot | 46440 lux / 4314.4 fc |
| @ 3m 6500K | 1261 lux / 117.1 fc | @ 3m 6500K Spot | 19099 lux / 1774.3 fc |
| @ 1m 6500K with Reflector | 42750 lux / 3971.6 fc | @ 1m 6500K Flood | 26520 lux / 2463.7 fc |
| @ 2m 6500K with Reflector | 9660 lux / 897.4 fc | @ 2m 6500K Flood | 7216 lux / 670.3 fc |
| @ 3m 6500K with Reflector | 4398 lux / 408.5 fc | @ 3m 6500K Flood | 3198 lux / 297.1 fc |
Dimensions
- Product Height (cm)
- 22.5
- Product Height (in)
- 8.86
- Product Length (cm)
- 33
- Product Length (in)
- 12.99
- Product Weight (kg)
- 2.7
- Product Weight (lb)
- 6.4
- Product Width (cm)
- 12
- Product Width (in)
- 4.72
Special Effects
CCT LOOP/ INT LOOP/ FLASH/ PULSE/STORM/ TV/ PAPARAZZI/ CANDLE/FIRE/ BAD BULB/ FIREWORK/ EXPLOSION AND WELDING
