Nanlite MixPad 11 Adjustable Bicolor Tunable RGB Dimmable Hard and Soft Light AC/Battery Powered LED Panel

SKU: 15-2005 | FREE U.S. shipping on all orders over $100!

$129.00
Students and Educators: Enroll or Log in for exclusive EDU savings!
Notify me Find a dealer
  • STUDIO QUALITY LIGHTING - Nanlite MixPad series LED panels create bright, color accurate, studio lighting with minimal set up and zero complications. Perfect for live streaming, vlogging, photography lighting, video lighting, photo booths and more.
  • THREE LED LIGHT SOURCES IN ONE COMPACT PANEL - Switch between a "traditional" multi LED panel for hard light, a diffuse SMD LED panel for soft light and a Tunable RGB panel for colorful creative effects at the push of a button.
  • FULL CREATIVE CONTROL- Easily achieve beautiful results without adding plastic filters or cloth diffusion. The MixPad 11's control knobs enable you to dial in brightness from 0-100%, temperature from warm to cold (3200K-5600K) or hue when in RGB mode.
  • COMPACT DESIGN - At only 1.4 inches thick and weighing just .9lbs the MixPad 11 is a perfect carry everywhere light whether you are mounting it on camera or off.
  • WE'VE GOT YOU COVERED - For over 25 years Nanlite has been producing innovative LED lighting solutions backed by a 2 year limited warranty extendible to 3 years limited with registration. Warranty valid only on products purchased from authorized dealers.

Overview

Nanlite MixPad series LED panels incorporate three LED light sources into one compact light fixture. Switch between a "traditional" multi-LED source producing a harder light; surface mount (SMD) LEDs that provide a soft light, and Red, Green and Blue LEDs which can be mixed to create more than 360 colors at the touch of a button. Whether you need hard lighting with more throw, diffused lighting for flattering portraits and up close work, or colored light to set moods and express emotions you can do it all in one unit with no additional accessories. Applications include creating a variety of background colors by directing the RGB light onto a plain white wall or canvas, adding interesting hues and highlights to portrait photography, and setting mood and tone for music videos, short films, or any video production. At only 1.4 thick, the MixPad 11 can provide up to 902 lumens (603Lux @ 1m 5600K, 471 lux @ 1m 3200K) of illumination. Supplied with a combination cold shoe - 1/4" 20 mount, the MixPad 11 can either be mounted directly on your camera, a light stand or tripod. With MixPad series LED panels you can quickly achieve beautiful, studio-quality results without adding plastic filters or cloth diffusion. Control knobs enable you to dial in brightness from 0-100%, temperature from warm to cold (3200K-5600K), and hue when in RGB mode. A rear-facing display shows the color temperature, brightness level, and hue information, allowing you to make precision adjustments and making it easy to recreate your lighting set up in future if you need to. The Nanlite MixPad 11 is a perfect carry everywhere light. Powered by either AC power adapter, Sony NP-F style batteries or DC through D-tap cable (AC adapter, batteries and D-tap cable sold separately), and it also features a built in battery level indicator.

Technical Data

Accepts Grids:
Not Applicable
Accessory Port(s):
Not Applicable
Amp-Hours:
Not Applicable
Battery Capacity (Wh):
Not Applicable
Battery Cells:
Not Applicable
Battery Chemistry:
Not Applicable
Battery Compatibility:
Sony NP-F550 / F750 / F970 series (Not Included)
Battery Included:
No
Battery Maximum Output Voltage:
Not Applicable
Battery Required:
No
Beam Angle Flood:
Not Applicable
Beam Angle Spot:
Not Applicable
Channels:
Not Applicable
Charge Time to Full (Hours):
Battery Dependent
Charge Time to 80% (Hours):
Battery Dependent
Charger:
Not Included
Closed Length (cm):
Not Applicable
Closed Length (in):
Not Applicable
Color Temperature (Kelvin):
3200K-5600K
Compatible D-Tap Adapter:
Nanlite CB-DT-DC D-Tap cable with DC Socket
Compatible Remote:
Nanlite RC-1 Remote Control
Compatible Wifi Adapter:
Nanlite W-2 Wifi Adapter
Cooling System:
Passive
CRI:
95
Depth Rating:
Not Applicable
Dimming:
0-100%
DMX Control:
No
Electrical Load Capacity:
Not Applicable
Footprint Diameter (cm):
cm
Footprint Diameter (in):
in
Frequency:
2.4ghz
Groups:
Not Applicable
Includes Rechargeable Battery:
No
Interior Color:
Not Applicable
Light Modifier Bayonet Mount:
Not Applicable
Load Capacity (kg):
Not Applicable
Load Capacity (lb):
Not Applicable
Lumen Output 3200K:
902
Lumen Output 5600K:
902
Lux @ 0.5m 5600K:
Not Applicable
Lux @ 1m 2700K:
Not Applicable
Lux @ 1m 3200K:
Soft Light Mode - 93 Hard Light Mode - 471
Lux @ 1m 5600K:
Soft Light Mode - 107 Hard Light Mode - 603
Max Power Consumption:
11w
Maximum Height (in):
Not Applicable
Maximum Height (cm):
Not Applicable
Physical:

Minimum Height (cm):
Not Applicable
Minimum Height (in):
Not Applicable
Mount:
1/4 20" and Cold Shoe
Number of Rods:
Not Applicable
Operating Temperature:
Not Applicable
Power Source:
7.2-15V DC
'Product Diameter (cm):
Not Applicable
'Product Diameter (in):
Not Applicable
Product Inner Diameter (cm) Ring Lights Only:
Not Applicable
Product Inner Diameter (in) Ring Lights Only:
Not Applicable
Product Height (cm):
13.21cm
Product Height (in):
5.2in
Product Length (cm):
17.78cm
Product Length (in):
7.0in
Product Weight (kg):
0.43kg
Product Weight (lb):
0.95lb
Product Width (cm):
4.06cm
Product Width (in):
1.6in
Removable Front Diffusion:
Not Applicable
Removable Interior Baffle:
Not Applicable
Requires Speed Ring:
Not Applicable
Runtime @ 100% Brightness (Hours):
1 x NP-F550: 1.4 hours 1 x NP-F750: 2.8 hours 1 x NP-F970: 4 hours
Runtime @ 50% Brightness (Hours):
1 x NP-F550: 2.8 hours 1 x NP-F750: 5.6 hours 1 x NP-F970: 8 hours
Runtime @ 10% Brightness (Hours):
1 x NP-F550: 14 hours 1 x NP-F750: 28 hours 1 x NP-F970: 40 hours
Shape:
Not Applicable
TLCI:
93
Umbrella Shaft Diameter:
Not Applicable
Warranty:
Limited 2 Year Warranty (Extend to 3 Years Total With Online Registration)
Wireless Control Type:
Wireless Remote / Wifi via adapter
Wireless Range:
Not Applicable
