Nanlite MixPad 27 Adjustable Bicolor Tunable RGB Dimmable Hard and Soft Light LED 3 Panel Kit (Open Box)

SKU: 15-2006-3KITD | FREE U.S. shipping on all orders over $100!

Regular: $1,099.00
SALE: $549.50
Students and Educators: Enroll or Log in for exclusive EDU savings!
Find a dealer
  • This product is in like-new condition and is offered for sale here because it was returned immediately after purchase or is was displayed at a trade show. OPEN BOX products are subject to the same warranty as NEW products. OPEN BOX Specials are also subject to the same 30-day return policy as NEW PRODUCTS.
  • STUDIO QUALITY LIGHTING - Nanlite RGB series LED panels create bright, color accurate, studio lighting with minimal set up and zero complications. Perfect for live streaming, vlogging, photography lighting, video lighting, photo booths and more.
  • THREE LED LIGHT SOURCES IN ONE COMPACT PANEL - Switch between a "traditional" multi LED panel for hard light, a diffuse SMD LED panel for soft light and a Tunable RGB panel for colorful creative effects at the push of a button.
  • FULL CREATIVE CONTROL- Easily achieve beautiful results without adding plastic filters or cloth diffusion. The MixPad 27's control knobs enable you to dial in brightness from 0-100%, temperature from warm to cold (3200K-5600K) or hue when in RGB mode.
  • POWER ANYWHERE - Perfect for use in the studio or on location, the MixPad 27 can run off either the included AC adapter, 2x Sony NP-F batteries (Not Included) or D-tap cable (not included), so you can operate in any location regardless power availability.
  • WE'VE GOT YOU COVERED - For over 25 years Nanlite has been producing innovative LED lighting solutions backed by a 2 year limited warranty extendible to 3 years limited with registration. Warranty valid only on products purchased from authorized dealers.

Overview

Nanlite MixPad series LED panels incorporate three LED light sources into one compact light fixture. Switch between a "traditional" multi-LED source producing a harder light; surface mount (SMD) LEDs that provide a soft light, and Red, Green and Blue LEDs which can be mixed to create more than 360 colors at the touch of a button. Whether you need hard lighting with more throw, diffused lighting for flattering portraits and up close work, or colored light to set moods and express emotions you can do it all in one unit with no additional accessories. Applications include creating a variety of background colors by directing the RGB light onto a plain white wall or canvas, adding interesting hues and highlights to portrait photography, and setting mood and tone for music videos, short films, or any video production. At only 2.2 inches thick, the MixPad 27 can provide up to 2508 lumens (2188 Lux @ 1m 5600K, 1757 Lux @ 1m 3200K) of illumination. Supplied with a standard 5/8" receiver mount, the MixPad 27 can be mounted directly on any standard light stand. With MixPad series LED panels you can quickly achieve beautiful, studio-quality results without adding plastic filters or cloth diffusion. Control knobs enable you to dial in brightness from 0-100%, temperature from warm to cold (3200K-5600K), and hue when in RGB mode. A rear-facing display shows the color temperature, brightness level, and hue information, allowing you to make precision adjustments and making it easy to recreate your lighting set up in future if you need to. The Nanlite MixPad 27 is ideal for use in the studio or on location. Choose from multiple power options including the AC power adapter (included) , Sony NP-F style batteries (sold separately) or DC through D-tap cable(sold separately), and it also features a built in battery level indicator.

Technical Data

Battery Compatibility:
Sony NP-F550 / F750 / F970 series (Not Included)
Battery Included:
No
Battery Required:
No
Charge Time to Full (Hours):
Battery Dependent
Charge Time to 80% (Hours):
Battery Dependent
Charger:
Not Included
Color Temperature (Kelvin):
3200K-5600K
Compatible D-Tap Adapter:
Nanlite CB-DT-DC D-Tap cable with DC Socket
Compatible Remote:
Nanlite RC-1 Remote Control
Compatible Wifi Adapter:
Nanlite W-2 Wifi Adapter
Cooling System:
Passive
CRI:
95
Dimming:
0-100%
DMX Control:
No
Frequency:
2.4ghz
Includes Rechargeable Battery:
No
Lumen Output 3200K:
2508
Lumen Output 5600K:
2508
Lux @ 1m 3200K:
Soft Light Mode - 433 Hard Light Mode - 1757
Lux @ 1m 5600K:
Soft Light Mode - 445 Hard Light Mode - 2188
Max Power Consumption:
27w
Physical:

Mount:
0
Power Source:
12-24V DC
Product Height (cm):
35.2cm
Product Height (in):
13.86in
Product Length (cm):
50.0cm
Product Length (in):
19.69in
Product Weight (kg):
9.74kg
Product Weight (lb):
21.47lb
Product Width (cm):
29.8cm
Product Width (in):
11.73in
Runtime @ 100% Brightness (Hours):
2 x NP-F550: 1.2 hours 2 x NP-F750: 2.4 hours 2 x NP-F970: 3.6 hours
Runtime @ 50% Brightness (Hours):
2 x NP-F550: 2.4 hours 2 x NP-F750: 4.8 hours 2 x NP-F970:7.2 hours
Runtime @ 10% Brightness (Hours):
2 x NP-F550: 12 hours 2 x NP-F750: 24 hours 2 x NP-F970: 36 hours
TLCI:
93
Warranty:
Limited 2 Year Warranty (Extend to 3 Years Total With Online Registration)
Wireless Control Type:
Wireless Remote / Wifi via adapter
Accepts Grids:
Not Applicable
Accessory Port(s):
Not Applicable
Amp-Hours:
Not Applicable
Battery Capacity (Wh):
Not Applicable
Battery Cells:
Not Applicable
Battery Chemistry:
Not Applicable
Battery Maximum Output Voltage:
Not Applicable
Beam Angle Flood:
Not Applicable
Beam Angle Spot:
Not Applicable
Channels:
Not Applicable
Closed Length (cm):
Not Applicable
Closed Length (in):
Not Applicable
Depth Rating:
Not Applicable
Electrical Load Capacity:
Not Applicable
Footprint Diameter (cm):
cm
Footprint Diameter (in):
in
Groups:
Not Applicable
Interior Color:
Not Applicable
Light Modifier Bayonet Mount:
Not Applicable
Load Capacity (kg):
Not Applicable
Load Capacity (lb):
Not Applicable
Lux @ 0.5m 5600K:
Not Applicable
Lux @ 1m 2700K:
Not Applicable
Maximum Height (in):
Not Applicable
Maximum Height (cm):
Not Applicable
Minimum Height (cm):
Not Applicable
Minimum Height (in):
Not Applicable
Number of Rods:
Not Applicable
Operating Temperature:
Not Applicable
'Product Diameter (cm):
Not Applicable
'Product Diameter (in):
Not Applicable
Product Inner Diameter (cm) Ring Lights Only:
Not Applicable
Product Inner Diameter (in) Ring Lights Only:
Not Applicable
Removable Front Diffusion:
Not Applicable
Removable Interior Baffle:
Not Applicable
Requires Speed Ring:
Not Applicable
Shape:
Not Applicable
Umbrella Shaft Diameter:
Not Applicable
Wireless Range:
Not Applicable
