Nanlite MixPanel 60 Bicolor + RGB Hard and Soft Light LED Panel (Open Box)

SKU: 15-2010D | FREE U.S. shipping on all orders over $100!

Regular: $899.00
SALE: $449.50
Students and Educators: Enroll or Log in for exclusive EDU savings!
Find a dealer
  • This product is in like-new condition and is offered for sale here because it was returned immediately after purchase or is was displayed at a trade show. OPEN BOX products are subject to the same warranty as NEW products. OPEN BOX Specials are also subject to the same 30-day return policy as NEW PRODUCTS.
  • THREE LED LIGHT SOURCES IN ONE COMPACT PANEL- Nanlite MixPanels are capable of switching between a "traditional" multi-LED panel for hard light, a diffuse SMD LED panel for soft light and a Tunable RGB panel for creative effects at the push of a button.
  • ULTRA - BRIGHT OUTPUT- In hard light boost mode the MixPanel 60 emits an impressive 6600 Lux at 1m 5600K. Plus with dimming from 100% down to 1%, you can quickly adapt the MixPanel 60 to any scene without adding ND gel or diffusion.
  • COLOR PERFECTION - The MixPanel 60 features a CRI of 98, a TLCI of 95 plus Green/Magenta adjustment in CCT mode, meaning you can shoot with confidence knowing the color reproduction will be precise.
  • INTUITIVE USER INTERFACE – The MixPanel 60's operating system has been developed from the ground up to be efficient and intuitive to use. What's more, you can save your settings as presets to make your lighting consistent and repeatable.
  • GEL EMULATION AND PRACTICAL EFFECTS - The MixPanel 60 provides a selection of 43 gel presets in two light sources (3200K & 5600K) and 9 special effects making it possible to imitate lighting scenarios that can otherwise be tricky to recreate.

Overview

The Nanlite MixPanel 60 uniquely combines three LED light sources into one compact housing, giving you the ability to switch between hard light, soft light, and colored light at the touch of a button. Coupled with ultra-bright light output, 0-100% dimming, a CRI of 98, a TLCI of 95, green/magenta adjustment, 43 gel presets in two light sources (3200K & 5600K), and 9 special effects; MixPanels are some of the most versatile RGBWW LED panels on the market.

Three LED Light Sources in One Compact Panel - Nanlite MixPanels are capable of switching between a "traditional" multi-LED panel for hard light, a diffuse SMD LED panel for soft light and a Tunable RGB panel for colorful, creative effects at the push of a button.

Now, whether you need hard lighting with more throw, diffused lighting for flattering portraits and up-close work, or colored light to set moods and express emotions, you can do it all in one unit with no additional accessories.

Ultra-Bright Output
When using the hard light fixture in normal mode, the MixPanel 60 emits an impressive 4980 Lux@1m 5600K. When shifted into boost mode the output climbs even higher to 6600 Lux at 1m. Plus with dimming from 100% down to 1%, you can quickly adapt the MixPanel 60 to any scene without adding ND gel or diffusion.

Color Perfection
The brightness of a light is important, but without color accuracy, a ton of time and money will be lost in post-production. The MixPanel 60 features a CRI of 98, a TLCI of 95 plus Green/Magenta adjustment in CCT mode, meaning you can shoot with confidence knowing the color reproduction will be precise.

Intuitive User Interface
If there is one thing an RGBWW LED panel can not be it's cumbersome to use on set. That is why the MixPanel 60's operating system has been developed from the ground up to be efficient and intuitive to use. What's more, you can save your settings as presets to make your lighting consistent and repeatable.

Gel Emulation and Practical Effects
The MixPanel's gel emulation mode provides a selection of 43 gel presets in two light sources (3200K & 5600K) encompassing 5x CTOx 5x CTB, and 33x Calcolor. Also, with 9 pre-programmed and adjustable special effects, the MixPanel makes it possible to imitate lighting scenarios that can otherwise be tricky to recreate such as hue loop, CCT loop, flash, pulse, storm, siren, TV screen, paparazzi, and candle/fire.

Power Anywhere
Optimized for use in the studio or on location, the MixPanel 60 can run off either the included AC adapter or 14.8V V-Mount batteries (Not Included), so you can operate in any location regardless of power availability.

Technical Data

Battery Compatibility:
Sony V-Mount 14.8v Battery(Not Included)
Battery Included:
0
Battery Required:
0
Charge Time to Full (Hours):
Battery Dependent
Charge Time to 80% (Hours):
Battery Dependent
Color Temperature (Kelvin):
2700K-7500K
Compatible Remote:
Nanlite RC-1 Remote Control
Compatible Wifi Adapter:
Nanlite W-2 Wifi Adapter
Cooling System:
Active cool/fan
CRI:
98
Dimming:
0-100%
DMX Control:
Yes
Frequency:
2.4ghz&DMX
Includes Rechargeable Battery:
0
Lux @ 1m 2700K:
Boost & Soft Light Mode -893 Boost & Hard Light Mode -5205 Normal & Soft Light Mode - 625 Normal & Hard Light Mode - 4245 Silent & Soft Light Mode - 453 Silent & Hard Light Mode - 3001
Lux @ 1m 3200K:
Boost & Soft Light Mode -892 Boost & Hard Light Mode -6015 Normal & Soft Light Mode - 680 Normal & Hard Light Mode - 4635 Silent & Soft Light Mode - 492 Silent & Hard Light Mode - 3293
Lux @ 1m 5600K:
Boost & Soft Light Mode -935 Boost & Hard Light Mode -6600 Normal & Soft Light Mode - 738 Normal & Hard Light Mode - 4980 Silent & Soft Light Mode - 513 Silent & Hard Light Mode - 3458
Max Power Consumption:
60W
Physical:

Mount:
Standard 5/8in Reciever
Power Source:
DC15V/6A
Product Height (cm):
35.0cm
Product Height (in):
14.0in
Product Length (cm):
43.0cm
Product Length (in):
17.0in
Product Weight (kg):
3.3kg
Product Weight (lb):
7.3lb
Product Width (cm):
8.2cm
Product Width (in):
3.0in
Runtime @ 100% Brightness (Hours):
14.8v Sony V-Mount 150wh: 2 hours
Runtime @ 50% Brightness (Hours):
14.8v Sony V-Mount 150wh: 4 hours
Runtime @ 10% Brightness (Hours):
14.8v Sony V-Mount 150wh:21 hours
TLCI:
95
Warranty:
Limited 2 Year Warranty (Extend to 3 Years Total With Online Registration)
Wireless Control Type:
Wireless Remote / Wifi via adapter
Accepts Grids:
Not Applicable
Accessory Port(s):
Not Applicable
Amp-Hours:
Not Applicable
Battery Capacity (Wh):
Not Applicable
Battery Cells:
Not Applicable
Battery Chemistry:
Not Applicable
Battery Maximum Output Voltage:
Not Applicable
Beam Angle Flood:
Not Applicable
Beam Angle Spot:
Not Applicable
Channels:
Not Applicable
Charger:
Not Applicable
Closed Length (cm):
Not Applicable
Closed Length (in):
Not Applicable
Compatible D-Tap Adapter:
Not Applicable
Depth Rating:
Not Applicable
Electrical Load Capacity:
Not Applicable
Footprint Diameter (cm):
cm
Footprint Diameter (in):
in
Groups:
Not Applicable
Interior Color:
Not Applicable
Light Modifier Bayonet Mount:
Not Applicable
Load Capacity (kg):
Not Applicable
Load Capacity (lb):
Not Applicable
Lumen Output 3200K:
Not Applicable
Lumen Output 5600K:
Not Applicable
Lux @ 0.5m 5600K:
Not Applicable
Minimum Height (cm):
Not Applicable
Minimum Height (in):
Not Applicable
Number of Rods:
Not Applicable
Operating Temperature:
Not Applicable
'Product Diameter (cm):
Not Applicable
'Product Diameter (in):
Not Applicable
Product Inner Diameter (cm) Ring Lights Only:
Not Applicable
Product Inner Diameter (in) Ring Lights Only:
Not Applicable
Removable Front Diffusion:
Not Applicable
Removable Interior Baffle:
Not Applicable
Requires Speed Ring:
Not Applicable
Shape:
Not Applicable
Umbrella Shaft Diameter:
Not Applicable
Wireless Range:
Not Applicable
