- Get Unique, Studio Quality Lighting Anywhere - With an expanded and more precise color temperature range from 2700K–12000K with green to magenta adjustment, an average CRI of 97, an average TLCI of 98, plus full-spectrum RGB hue and saturation control, the PavoTube II 60X 8' RGBWW LED Pixel Tube packs studio-quality lighting into a hardy package.
- From a Next-Generation LED Tube - Nanlite drew on the feedback from PavoTube owners across the world to evolve their LED Tube design. Enhancements include brighter output with more uniform diffusion, an upgraded control panel with locking buttons, DMX compatibility, and wireless 2.4G and Bluetooth control with the free NANLINK mobile app for iOS and Android.
- With No Cords Needed - Powered an internal 8800mAh Li-ion battery, the PavoTube II 60X can run for 1 hour and 57 minutes at full brightness completely untethered. Full battery recharge is achieved in 5 hours and 30 minutes via the included AC adapters, which can also power the Pavotube II 60X during longer shoots.
- Pixel Based Special Effects - In addition to 15 adjustable practical special effects, PavoTube II 60X features 10 new pixel-based effects expanding the creative possibilities further than ever before. Pixel-based effects include Hue Loop, CCT Loop, INT Loop, Multi-color, Gradient, Scrolling, Marching, Flame, Rainbow, and Driving.
- And A Robust Metal Housing - The PavoTube II 60X's upgraded metal housing makes worrying about an accidental drop or risky light placements a thing of the past. Plus, three incorporated ¼-20" receivers greatly expand mounting options.
Overview
The Nanlite PavoTube II RGBWW LED Pixel Tubes are the next evolution of Nanlite's signature light fixtures. These second-gen LED Tubes have been refined based on feedback from creators around the globe with features including pixel-based special effects, brighter output, more uniform diffusion, robust metal housings, DMX compatibility, and wireless 2.4G and Bluetooth control with the free NANLINK mobile app for iOS and Android.
Get Unique, Studio Quality Lighting Anywhere
With an expanded and more precise color temperature range from 2700K-12000K with green to magenta adjustment, an average CRI of 97, an average TLCI of 98, plus full-spectrum RGB hue and saturation control, the PavoTube II 60X 8' RGBWW LED Pixel Tube packs studio-quality lighting into a hardy, portable package.
From a Next-Generation LED Tube
Nanlite drew on the feedback from PavoTube owners across the world to evolve their LED Tube design. Enhancements include brighter output from a larger illumination area with more uniform diffusion, a pixel density of 32 to create eye-catching animated effects, an upgraded control panel with locking buttons, DMX compatibility, and full wireless control through 2.4G and Bluetooth with the free NANLINK mobile app for iOS and Android.
With No Cords Needed
Powered by an internal 8800mAh Li-ion battery, the PavoTube II 60X can run for 1 hour and 57 minutes at full brightness completely untethered. Battery recharge is achieved with the included AC adapter, which can also keep the PavoTube II 60X powered on during longer shoots.
Pixel Based Special Effects
In addition to 15 adjustable practical special effects, PavoTube II 60X features 10 new pixel-based effects expanding the creative possibilities further than ever before. Pixel-based effects include Hue Loop, CCT Loop, INT Loop, Multi-color, Gradient, Scrolling, Marching, Flame, Rainbow, and Driving. Practical effects include Hue Loop, CCT Loop, INT Loop, CCT Flash, HUE Flash, CCT Pulse, Hue Pulse, Storm, Police Car, TV, Paparazzi, Candle/Fire, Disco, Bad Bulb, Firework, Explosion, and Welding.
And A Robust Metal Housing
The PavoTube II 60X's upgraded metal housing makes worrying about an accidental drop or risky light placements a thing of the past. Plus, three incorporated ¼-20" receivers greatly expand mounting options.
Get Unique, Studio Quality Lighting Anywhere
With an expanded and more precise color temperature range from 2700K-12000K with green to magenta adjustment, an average CRI of 97, an average TLCI of 98, plus full-spectrum RGB hue and saturation control, the PavoTube II 60X 8' RGBWW LED Pixel Tube packs studio-quality lighting into a hardy, portable package.
From a Next-Generation LED Tube
Nanlite drew on the feedback from PavoTube owners across the world to evolve their LED Tube design. Enhancements include brighter output from a larger illumination area with more uniform diffusion, a pixel density of 32 to create eye-catching animated effects, an upgraded control panel with locking buttons, DMX compatibility, and full wireless control through 2.4G and Bluetooth with the free NANLINK mobile app for iOS and Android.
With No Cords Needed
Powered by an internal 8800mAh Li-ion battery, the PavoTube II 60X can run for 1 hour and 57 minutes at full brightness completely untethered. Battery recharge is achieved with the included AC adapter, which can also keep the PavoTube II 60X powered on during longer shoots.
Pixel Based Special Effects
In addition to 15 adjustable practical special effects, PavoTube II 60X features 10 new pixel-based effects expanding the creative possibilities further than ever before. Pixel-based effects include Hue Loop, CCT Loop, INT Loop, Multi-color, Gradient, Scrolling, Marching, Flame, Rainbow, and Driving. Practical effects include Hue Loop, CCT Loop, INT Loop, CCT Flash, HUE Flash, CCT Pulse, Hue Pulse, Storm, Police Car, TV, Paparazzi, Candle/Fire, Disco, Bad Bulb, Firework, Explosion, and Welding.
And A Robust Metal Housing
The PavoTube II 60X's upgraded metal housing makes worrying about an accidental drop or risky light placements a thing of the past. Plus, three incorporated ¼-20" receivers greatly expand mounting options.
Technical Data
- Accepts Grids:
- Not Applicable
- Accessory Port(s):
- No
- Amp-Hours:
- 8800mAh
- Battery Capacity (Wh):
- 162.8
- Battery Cells:
- 20
- Battery Chemistry:
- Li-Ion
- Battery Compatibility:
- N/A
- Battery Included:
- Yes
- Battery Maximum Output Voltage:
- 18.5V
- Battery Required:
- Yes
- Beam Angle Flood:
- Not Applicable
- Beam Angle Spot:
- Not Applicable
- Channels:
- Not Applicable
- Charge Time to Full (Hours):
- About 5 hours 30 mins
- Charge Time to 80% (Hours):
- N/A
- Charger:
- AC Adapter
- Closed Length (cm):
- Not Applicable
- Closed Length (in):
- Not Applicable
- Color Temperature (Kelvin):
- 2700K-12000K
- Compatible D-Tap Adapter:
- Not Applicable
- Compatible Remote:
- WS-RC-C2 remote control
- Compatible Wifi Adapter:
- Nanlink WS-TB-1 Transmitter box
- Cooling System:
- No
- CRI:
- Average 97
- Depth Rating:
- IP20
- Dimming:
- 0-100%
- DMX Control:
- Yes
- Electrical Load Capacity:
- 48W
- Footprint Diameter (cm):
- cm
- Footprint Diameter (in):
- in
- Frequency:
- 2.4Ghz
- Groups:
- Not Applicable
- Includes Rechargeable Battery:
- Yes
- Interior Color:
- Not Applicable
- Light Modifier Bayonet Mount:
- Not Applicable
- Load Capacity (kg):
- Not Applicable
- Load Capacity (lb):
- Not Applicable
- Lux @ 0.5m 5600K:
- 2324
- Lux @ 1m 2700K:
- 900
- Lux @ 1m 3200K:
- 928
- Lux @ 1m 5600K:
- 991
- Max Power Consumption:
- 106W
- Maximum Height (in):
- Not Applicable
- Maximum Height (cm):
- Not Applicable
- Physical:
- Minimum Height (cm):
- Not Applicable
- Minimum Height (in):
- Not Applicable
- Mount:
- T12, 3x 1/4 20"
- Number of Rods:
- Not Applicable
- Operating Temperature:
- ta40℃
- Power Source:
- DC15V/6.5A
- 'Product Diameter (cm):
- 4.3
- 'Product Diameter (in):
- 1.7
- Product Inner Diameter (cm) Ring Lights Only:
- Not Applicable
- Product Inner Diameter (in) Ring Lights Only:
- Not Applicable
- Product Height (cm):
- cm
- Product Height (in):
- 3.9in
- Product Length (cm):
- 222.0cm
- Product Length (in):
- 99.0in
- Product Weight (kg):
- 6.0kg
- Product Weight (lb):
- 28.7lb
- Product Width (cm):
- cm
- Product Width (in):
- 7.1in
- Removable Front Diffusion:
- Not Applicable
- Removable Interior Baffle:
- Not Applicable
- Requires Speed Ring:
- Not Applicable
- Runtime @ 100% Brightness (Hours):
- 1h 57 mins
- Runtime @ 50% Brightness (Hours):
- 4h
- Runtime @ 10% Brightness (Hours):
- 18h
- Shape:
- Not Applicable
- TLCI:
- Average 98
- Umbrella Shaft Diameter:
- Not Applicable
- Warranty:
- Limited 2 Year Warranty (Extend to 3 Years Total With Online Registration)
- Wireless Control Type:
- 2.4GHz, Bluetooth, DMX/RDM
- Wireless Range:
- Not Applicable
