Saramonic Blink 500 ProX TXR Transmitter w/ On-Board Recording & Lavalier for ProX RX, RXDi & RXUC Receivers

SKU: BLINK500PROXTXR | FREE U.S. shipping on all orders over $100!

$79.00

Students and Educators: Enroll or Log in for exclusive EDU savings!

Clip-on transmitter with on-board recording, built-in omnidirectional microphone and SR-M1 Lavalier for Blink 500 ProX RX, RXDi and RXUC receivers
Features 8GB of 24-bit / 48kHz on-board recording for up to 14.8-hours of lossless .wav back-up audio recording and controlled by an inset tactile switch, so it cannot be turned off accidently when recording
Features a built-in omnidirectional mic and can be clipped to clothing or used as a traditional belt pack with the included lavalier for a more discrete miking solution
Features input level control, mute, and selectable line-level input to wireless transmit and record line-level audio, with up to 10-hour battery run time, and 328-feet (100m) range
Upgrade transmitter with on-board recorder, spare or replacement for lost or damaged transmitter for your Blink 500 ProX B1, B2, B3, B4, B5, or B6 wireless system

Overview

The Saramonic Blink 500 ProX TXR is a compact and lightweight clip-on wireless microphone transmitter with on-board recording and included lavalier that is designed to work with the Blink 500 ProX RX, RXDi, and RXUC portable dual receivers. The Blink 500 ProX TXR is designed to be an upgrade for non-recording Blink 500 ProX transmitters in the B1, B2, B3, B4, B5, and B6 systems. It can also be used as a spare or replacement for a lost or damaged transmitter, and as a second transmitter to expand your single transmitter Blink 500 ProX B1, B3 or B5 wireless system. Since all the receivers can handle up to two transmitters at the same time, you can outfit any Blink 500 ProX RX, RXDi, and RXUC receiver with up to 2x Blink 500 ProX TXRs. ***Designed exclusively for the Blink 500 ProX Receivers and Systems, and will not work with the Blink 500 or Blink 500 Pro receivers or systems***

24-bit / 48kHz Recording Transmitter that is Incredibly Easy-to-Use
The Blink 500 ProX TXR transmitter features 8GB of onboard recording for up to 14 hours and 50 minutes of 24-bit/48kHz lossless .wav backup recording. Allowing you to record back-up audio directly to the transmitter in case of interference or dropouts. The built-in recorder is controlled by a tactile switch, making it easy to turn on and off with no menus fiddle with. Because the switch is inset, you can be sure it won’t get turned off accidently when recording. You can also use the transmitter as a standalone recorder for even more flexibility. Extracting the audio files is just as easy, simply connect the transmitter to your computer and drag the audio files to your desktop. There is no specialized app or additional processing needed to extract the audio file. So, when you need the audio, you can access it fast with no fuss.

Tiny and Light TX Transmitter and Included Lavalier, with Big and Heavy Features
The Blink 500 ProX TXR transmitter features a built-in omnidirectional microphone with an impressive sensitivity of -39dB. Giving you professional dynamic sound quality on a transmitter small and light enough that you can easily clip it to a shirt or collar. The transmitter also includes a lavalier microphone, allowing you to use it as traditional belt pack transmitter for an even more discreet and professional miking solution. Its tactile input gain control allows you to adjust the audio gain with ease, and a soft-touch mute button lets you quickly mute the transmitter for privacy.

Wireless Transmit and Record Line-Level Audio and Other 3.5mm Microphones
The Blink 500 ProX TXR transmitter also allows you to transmit wirelessly and record line-level signal or microphone-level and provide plug-in power to microphones. This stand-out feature makes the transmitter tremendously versatile, allowing you to connect it to virtually any audio source. Switch the TXR transmitter to line-level and connect it to mixers, music players, or any line-level device output you want to transmit wirelessly to the receiver or record. You can use the included SR-M1 lavalier, or you can add a headset microphone, a higher-end lavalier like the Saramonic DK3G, or even plug in a mini-shotgun microphone. Just about any 3.5mm microphone wired for standard TRS pin-out will work, and the adjustable mic gain lets you get perfect levels every time.

Remarkable Power and Convenience for Creators on the Move
The Blink 500 ProX TXR features a battery life of up to 10-hours (8.5-hours when recording), nearly double the power of other 2.4GHz micro wireless systems. Giving users the ability to shoot for an entire day on one charge! Because the transmitter also features a USB-C charging port, it can be powered while in use or charged outside of a system’s charging case using USB battery packs or a power supply for even more powering versatility.

Specifications

TXR Transmitter Specifications:
Transmission Type: 2.4GHz Digital Frequency
Modulation: Digital Modulation
Antenna: Built-In FPC Antenna
Operating Range (Without Obstacles): Up to 328' (100m)
RF Output Power: <10mW
Frequency Response 20Hz to 20KHz
Recording Resolution: 24-bit / 48kHz
Recording Memory Capacity: 8GB (Approximately 14 Hours & 50 Minutes)
Reference Audio Input Level: -20~-42dBv (Mic input, 0dB Attenuation)
Input Connector: 3.5mm Mic In / Line In (Mic with Plug-in-Power)
Built-in Microphone Polar Pattern: Omnidirectional
Built-in Microphone Maximum SPL: 106dB
Built-in Microphone Sensitivity: 39±2dB (Tested at 2V 2.2KΩ)
Lavalier Microphone Maximum SPL: 120dB
Lavalier Microphone Sensitivity: 39+/-2dB (0dB=1V/Pa,1kHz)
Digital Signal Resolution: 16bit / 48kHz
Signal-to-Noise Ratio: ≥84dB
Distortion: ≤0.1%
High-contrast OLED Screen Resolution: 128 x 64 pixels
Other Functions: Tactile Microphone Mute Function
Power Requirements: Built-in Li-ion Battery, USB-C DC 5V or Charging Contact
Battery Life Recording On: Approximately 8.5-hours
Battery Life Recording Off: Approximately 11-hours
Battery Specifications: 3.7V / 400mAh
Weight: 1.04oz (29.5g)
Dimensions: 2.2 x 1.49 x 0.61” (56 × 38 × 15.5mm)
Operating Temperatures: 0° to 122°F (0°C to 50°C)
Storage Temperatures: -50° to 122°F (–10°C to +50°C)

SR-M1 Lavalier Specifications:
Acoustic Principle: Electret Condenser
Polar Pattern: Omnidirectional
Connector: 3.5mm
Cable Length: 4.1’ (1.25m)
Maximum SPL: 110dB
Sensitivity: -39dB+/-2dB(0dB=1V/Pa,1kHz)
Signal-to-Noise Ratio: ≥60dB
THD: <1% (94dB SPL at 1kHz)
Power Requirements: Plug-in-Power (1V?10V)
Standard Operating Voltage: 3V
Current Consumption: <500μA
Output Impedance: <2.2KΩ
